ACS37800 是一款集成式功率监控 IC，设计用于交流和直流应用，可精确测量有功功率、无功功率、视在功率以及功率因数。提供两种 SOICW-16 封装选择：MA 和 MC，这两种封装都具有加强隔离功能。MC 封装具有较低的内部导体电阻，可最大限度减少功率耗散，因此适用于较大电流的应用。
Product Details
Product Details
Top Features
- 用户可编程 VRMS 欠压/过压引脚
- 专用电压或电流过零引脚
- 用户可编程过流故障 (OCF)
- I2C 或 SPI 通信
- 电压、电流或功率三个输出中，两个输出的可编程平均值
Target Application
