磁気ポジション センサー
モーション、角度、直線位置をよりスマートにセンシング
Allegro の位置センサは、過酷な車載および産業環境下で、高精度な非接触の直線および回転測定を実現します。複数の出力プロトコルに対応しているため、これらのセンサは設計を簡素化し、システムの複雑性を低減し、安全性が重視されるアプリケーションにおいて高度な診断機能を可能にします。
Browse by category
リニア ポジション センサー IC
当社のリニアポジションセンサは、高度な線形化とエアギャップの変動に対する強い耐性により、高精度な1次元（1D）位置検出を実現します—精密な非接触モーショントラッキングが求められるアプリケーションに最適です。
角度ポジション センサー IC
Allegro の 2D 角度センサは、車載、産業、ロボットの各アプリケーションにおける高精度なモータ制御向けに、アナログおよび超低レイテンシー (~10 µs) のデジタル出力を提供します。当社のセンサは、ASIL-D 準拠、デュアルダイ冗長性、および最大 ±0.3° の角度精度により、スムーズで効率的、かつ信頼性の高い動作を保証します。
3 次元磁気速度センサー
Allegroの3DMAG™多軸センサは、浮遊磁場を排除しつつ3次元（3D）空間における複雑な直線運動および回転運動を捉えるように設計されており、機械設計の柔軟性と精度をさらに向上させます。
