Allegro's XtremeSense™ TMR technology
Superior magnetic sensitivity, low power consumption, and compact size compared to other technologies, driving innovation in applications like renewable energy, electric vehicles, and consumer electronics.
Product Details
Product Details
Top Features
- Total Output Error: <±0.5% (Typical)
- Resolution: 5 mA
- Sampling Frequency: 200 kHz
- Supply Current: 1.2 mA
- FLAG Pin to Indicate 90% and 10% of Full Current Range
- Supply Voltage: 2.7 V to 5.5 V
- 2kV Isolation
- AC or DC Current Range:
- +5.0 ADC / ±5.0 APK
- +10.0 ADC / ±10.0 APK
- +15.0 ADC / ±15.0 APK
- Package: 6-lead DFN, 3.00 x 3.00 x 0.95 mm
